2020 katalog indir

Last Updated on Feb. 10, 2020

2D ve 3D CAD dosyaları aşağıdaki tüm sayfalarda mevcuttur.

CS2P

No. Unit No. Bearing No. Shaft Dia. H L J Bolt Size Cr Cor
1 CS2P08-107 22208-107CS 1 7/16 in 1 7/8 in 6 5/8 in 5 in 1/2 in 20408 lbf 21623 lbf
2 CS2P08-108 22208-108CS 1 1/2 in 1 7/8 in 6 5/8 in 5 in 1/2 in 20408 lbf 21623 lbf
3 CS2P08-040 22208-040CS 40 mm 47.6 mm 168 mm 127 mm M12 90.7 kN 96.1 kN
4 CS2P09-111 22209-111CS 1 11/16 in 2 1/8 in 7 1/8 in 5 1/2 in 1/2 in 21150 lbf 23625 lbf
5 CS2P09-112 22209-112CS 1 3/4 in 2 1/8 in 7 1/8 in 5 1/2 in 1/2 in 21150 lbf 23625 lbf
6 CS2P09-045 22209-045CS 45 mm 54 mm 181 mm 140 mm M12 94 kN 105 kN
7 CS2P10-115 22210-115CS 1 15/16 in 2 1/4 in 8 in 6 1/4 in 5/8 in 22095 lbf 25313 lbf
8 CS2P10-050 22210-050CS 50 mm 57.2 mm 203 mm 159 mm M16 98.2 kN 112.5 kN
9 CS2P10-200 22210-200CS 2 in 2 1/4 in 8 in 6 1/4 in 5/8 in 22095 lbf 25313 lbf
10 CS2P11-055 22211-055CS 55 mm 63.5 mm 216 mm 170 mm M16 122 kN 145 kN
11 CS2P11-203 22211-203CS 2 3/16 in 2 1/2 in 8 1/2 in 6 3/4 in 5/8 in 27450 lbf 32625 lbf
12 CS2P11-204 22211-204CS 2 1/4 in 2 1/2 in 8 1/2 in 6 3/4 in 5/8 in 27450 lbf 32625 lbf
13 CS2P13-060 22213-060CS 60 mm 69.8 mm 225 mm 181 mm M16 178 kN 212 kN
14 CS2P13-207 22213-207CS 2 7/16 in 2 3/4 in 8 7/8 in 7 1/8 in 5/8 in 40050 lbf 47700 lbf
15 CS2P13-208 22213-208CS 2 1/2 in 2 3/4 in 8 7/8 in 7 1/8 in 5/8 in 40050 lbf 47700 lbf
16 CS2P13-065 22213-065CS 65 mm 69.8 mm 225 mm 181 mm M16 178 kN 212 kN
17 CS2P15-211 22215-211CS 2 11/16 in 3 1/4 in 10 5/16 in 8 1/8 in 3/4 in 42075 lbf 51300 lbf
18 CS2P15-212 22215-212CS 2 3/4 in 3 1/4 in 10 5/16 in 8 1/8 in 3/4 in 42075 lbf 51300 lbf
19 CS2P15-070 22215-070CS 70 mm 82.6 mm 262 mm 206 mm M20 187 kN 228 kN
20 CS2P15-215 22215-215CS 2 15/16 in 3 1/4 in 10 5/16 in 8 1/8 in 3/4 in 42075 lbf 51300 lbf
21 CS2P15-075 22215-075CS 75 mm 82.6 mm 262 mm 206 mm M20 187 kN 228 kN
22 CS2P15-300 22215-300CS 3 in 3 1/4 in 10 5/16 in 8 1/8 in 3/4 in 42075 lbf 51300 lbf
23 CS2P18-080 22218-080CS 80 mm 95.2 mm 321 mm 254 mm M22 302 kN 373 kN
24 CS2P18-304 22218-304CS 3 1/4 in 3 3/4 in 12 5/8 in 10 in 7/8 in 67950 lbf 83925 lbf
25 CS2P18-085 22218-085CS 85 mm 95.2 mm 321 mm 254 mm M22 302 kN 373 kN
26 CS2P18-307 22218-307CS 3 7/16 in 3 3/4 in 12 5/8 in 10 in 7/8 in 67950 lbf 83925 lbf
27 CS2P18-308 22218-308CS 3 1/2 in 3 3/4 in 12 5/8 in 10 in 7/8 in 67950 lbf 83925 lbf
28 CS2P18-090 22218-090CS 90 mm 95.2 mm 321 mm 254 mm M22 302 kN 373 kN
29 CS2P20-095 22220-095CS 95 mm 108 mm 384 mm 298 mm M24 371 kN 471 kN
30 CS2P20-100 22220-100CS 100 mm 108 mm 384 mm 298 mm M24 371 kN 471 kN
31 CS2P20-315 22220-315CS 3 15/16 in 4 1/4 in 15 1/8 in 11 3/4 in 1 in 83475 lbf 105975 lbf
32 CS2P20-400 22220-400CS 4 in 4 1/4 in 15 1/8 in 11 3/4 in 1 in 83475 lbf 105975 lbf

CS Yataklı Rulman Üniteleri Kurulumu

CS Yataklı Rulman Genişletme Üniteleri Kurulumu

2D ve 3D CAD dosyaları aşağıdaki tüm sayfalarda mevcuttur.

CS4P

No. Unit No. Bearing No. Shaft Dia. H L J BoltSize Cr Cor
1 CS4P13-060 22213-060CS 60 mm 69.8 mm 222 mm 181 mm M12 178 kN 212 kN
2 CS4P13-207 22213-207CS 2 7/16 in 2 3/4 in 8 3/4 in 7 1/8 in 1/2 in 40050 lbf 47700 lbf
3 CS4P13-208 22213-208CS 2 1/2 in 2 3/4 in 8 3/4 in 7 1/8 in 1/2 in 40050 lbf 47700 lbf
4 CS4P13-065 22213-065CS 65 mm 69.8 mm 222 mm 181 mm M12 178 kN 212 kN
5 CS4P15-211 22215-211CS 2 11/16 in 3 1/4 in 9 7/8 in 8 1/8 in 5/8 in 42075 lbf 51300 lbf
6 CS4P15-212 22215-212CS 2 3/4 in 3 1/4 in 9 7/8 in 8 1/8 in 5/8 in 42075 lbf 51300 lbf
7 CS4P15-070 22215-070CS 70 mm 82.6 mm 251 mm 206 mm M16 187 kN 228 kN
8 CS4P15-215 22215-215CS 2 15/16 in 3 1/4 in 9 7/8 in 8 1/8 in 5/8 in 42075 lbf 51300 lbf
9 CS4P15-075 22215-075CS 75 mm 82.6 mm 251 mm 206 mm M16 187 kN 228 kN
10 CS4P15-300 22215-300CS 3 in 3 1/4 in 9 7/8 in 8 1/8 in 5/8 in 42075 lbf 51300 lbf
11 CS4P18-080 22218-080CS 80 mm 95.2 mm 315 mm 254 mm M20 302 kN 373 kN
12 CS4P18-304 22218-304CS 3 1/4 in 3 3/4 in 12 13/32 in 10 in 3/4 in 67950 lbf 83925 lbf
13 CS4P18-085 22218-085CS 85 mm 95.2 mm 315 mm 254 mm M20 302 kN 373 kN
14 CS4P18-307 22218-307CS 3 7/16 in 3 3/4 in 12 13/32 in 10 in 3/4 in 67950 lbf 83925 lbf
15 CS4P18-308 22218-308CS 3 1/2 in 3 3/4 in 12 13/32 in 10 in 3/4 in 67950 lbf 83925 lbf
16 CS4P18-090 22218-090CS 90 mm 95.2 mm 315 mm 254 mm M20 302 kN 373 kN
17 CS4P20-095 22220-095CS 95 mm 108 mm 375 mm 310 mm M20 371 kN 471 kN
18 CS4P20-100 22220-100CS 100 mm 108 mm 375 mm 310 mm M20 371 kN 471 kN
19 CS4P20-315 22220-315CS 3 15/16 in 4 1/4 in 14 3/4 in 12 7/32 in 3/4 in 83475 lbf 105975 lbf
20 CS4P20-400 22220-400CS 4 in 4 1/4 in 14 3/4 in 12 7/32 in 3/4 in 83475 lbf 105975 lbf
21 CS4P22-407 22222-407CS 4 7/16 in 4 3/4 in 16 1/2 in 13 5/16 in 3/4 in 136350 lbf 164475 lbf

CS Yataklı Rulman Üniteleri Kurulumu

CS Yataklı Rulman Genişletme Üniteleri Kurulumu

CX2SN28-125 – CX2SN32-140

2D ve 3D CAD dosyaları aşağıdaki tüm sayfalarda mevcuttur.

CX2SN

No. Unit No. Bearing No. Shaft Dia. Sleeve H L J Bolt Size Cr Cor
1 CX2SN11-115 22211-115CX 1 15/16 in AA2311X 2 3/4 in 10 1/32 in 8 1/4 in 5/8 in 27450 lbf 32625 lbf
2 CX2SN11-050 22211-050CX 50 mm A2311X 70 mm 255 mm 210 mm M16 122 kN 145 kN
3 CX2SN11-200 22211-200CX 2 in AE2311X 2 3/4 in 10 1/32 in 8 1/4 in 5/8 in 27450 lbf 32625 lbf
4 CX2SN12-202 22212-202CX 2 1/8 in AS2312X 2 3/4 in 10 1/32 in 8 1/4 in 5/8 in 34200 lbf 39375 lbf
5 CX2SN12-055 22212-055CX 55 mm A2312X 70 mm 255 mm 210 mm M16 152 kN 175 kN
6 CX2SN13-203 22213-203CX 2 3/16 in AA2313X 3 5/32 in 10 27/32 in 9 1/16 in 5/8 in 40050 lbf 47700 lbf
7 CX2SN13-204 22213-204CX 2 1/4 in AE2313X 3 5/32 in 10 27/32 in 9 1/16 in 5/8 in 40050 lbf 47700 lbf
8 CX2SN13-060 22213-060CX 60 mm A2313X 80 mm 275 mm 230 mm M16 178 kN 212 kN
9 CX2SN13-206 22213-206CX 2 3/8 in AS2313X 3 5/32 in 10 27/32 in 9 1/16 in 5/8 in 40050 lbf 47700 lbf
10 CX2SN15-207 22215-207CX 2 7/16 in AA2315X 3 5/32 in 10 27/32 in 9 1/16 in 5/8 in 42075 lbf 51300 lbf
11 CX2SN15-208 22215-208CX 2 1/2 in AE2315X 3 5/32 in 10 27/32 in 9 1/16 in 5/8 in 42075 lbf 51300 lbf
12 CX2SN15-065 22215-065CX 65 mm A2315X 80 mm 275 mm 230 mm M16 187 kN 228 kN
13 CX2SN16-211 22216-211CX 2 11/16 in AA2316X 3 3/4 in 12 19/32 in 10 1/4 in 3/4 in 50175 lbf 60525 lbf
14 CX2SN16-212 22216-212CX 2 3/4 in AE2316X 3 3/4 in 12 19/32 in 10 1/4 in 3/4 in 50175 lbf 60525 lbf
15 CX2SN16-070 22216-070CX 70 mm A2316X 95 mm 320 mm 260 mm M20 223 kN 269 kN
16 CX2SN17-215 22217-215CX 2 15/16 in AA2317X 3 3/4 in 12 19/32 in 10 1/4 in 3/4 in 59175 lbf 71325 lbf
17 CX2SN17-075 22217-075CX 75 mm A2317X 95 mm 320 mm 260 mm M20 263 kN 317 kN
18 CX2SN17-300 22217-300CX 3 in AE2317X 3 3/4 in 12 19/32 in 10 1/4 in 3/4 in 59175 lbf 71325 lbf
19 CX2SN18-080 22218-080CX 80 mm A2318X 100 mm 345 mm 290 mm M20 302 kN 373 kN
20 CX2SN18-303 22218-303CX 3 3/16 in AA2318X 3 15/16 in 13 19/32 in 11 7/16 in 3/4 in 67950 lbf 83925 lbf
21 CX2SN19-304 22219-304CX 3 1/4 in AE2319X 4 13/32 in 13 19/32 in 11 7/16 in 3/4 in 74025 lbf 92700 lbf
22 CX2SN19-085 22219-085CX 85 mm A2319X 112 mm 345 mm 290 mm M20 329 kN 412 kN
23 CX2SN20-307 22220-307CX 3 7/16 in AA2320X 4 13/32 in 14 31/32 in 12 19/32 in 7/8 in 83475 lbf 105975 lbf
24 CX2SN20-308 22220-308CX 3 1/2 in AE2320X 4 13/32 in 14 31/32 in 12 19/32 in 7/8 in 83475 lbf 105975 lbf
25 CX2SN20-090 22220-090CX 90 mm A2320X 112 mm 380 mm 320 mm M24 371 kN 471 kN
26 CX2SN22-100 22222-100CX 100 mm A2322X 125 mm 410 mm 350 mm M24 606 kN 731 kN
27 CX2SN22-400 22222-400CX 4 in AE2322X 4 15/16 in 16 5/32 in 13 25/32 in 7/8 in 136350 lbf 164475 lbf
28 CX2SN24-403 22224-403CX 4 3/16 in AA2324X 5 1/2 in 16 5/32 in 13 25/32 in 7/8 in 153000 lbf 193275 lbf
29 CX2SN24-404 22224-404CX 4 1/4 in AE2324X 5 1/2 in 16 5/32 in 13 25/32 in 7/8 in 153000 lbf 193275 lbf
30 CX2SN24-110 22224-110CX 110 mm A2324X 140 mm 410 mm 350 mm M24 680 kN 859 kN
31 CX2SN26-407 22226-407CX 4 7/16 in AA2326X 5 29/32 in 17 17/32 in 14 31/32 in 7/8 in 182250 lbf 260550 lbf
32 CX2SN26-408 22226-408CX 4 1/2 in AE2326X 5 29/32 in 17 17/32 in 14 31/32 in 7/8 in 182250 lbf 260550 lbf
33 CX2SN26-115 22226-115CX 115 mm A2326X 150 mm 445 mm 380 mm M24 810 kN 1158 kN
34 CX2SN28-125 22228-125CX 125 mm A2328X 150 mm 500 mm 420 mm M30 911 kN 1243 kN
35 CX2SN28-415 22228-415CX 4 15/16 in AA2328X 5 29/32 in 19 11/16 in 16 17/32 in 1 1/4 in 204975 lbf 279675 lbf
36 CX2SN28-500 22228-500CX 5 in AE2328X 5 29/32 in 19 11/16 in 16 17/32 in 1 1/4 in 204975 lbf 279675 lbf
37 CX2SN30-503 22230-503CX 5 3/16 in AA2330X 6 5/16 in 20 7/8 in 17 23/32 in 1 1/4 in 241425 lbf 312075 lbf
38 CX2SN30-504 22230-504CX 5 1/4 in AE2330X 6 5/16 in 20 7/8 in 17 23/32 in 1 1/4 in 241425 lbf 312075 lbf
39 CX2SN30-135 22230-135CX 135 mm A2330X 160 mm 530 mm 450 mm M30 1073 kN 1387 kN
40 CX2SN32-507 22232-507CX 5 7/16 in AA2332X 6 11/16 in 21 21/32 in 18 1/2 in 1 1/4 in 270000 lbf 393300 lbf
41 CX2SN32-508 22232-508CX 5 1/2 in AE2332X 6 11/16 in 21 21/32 in 18 1/2 in 1 1/4 in 270000 lbf 393300 lbf
42 CX2SN32-140 22232-140CX 140 mm A2332X 170 mm 550 mm 470 mm M30 1200 kN 1748 kN

CROSSLOC™ Üniteleri Montajı ve Demontajı

CROSSLOC™ Genişletme Üniteleri Montajı ve Demontajı

2D ve 3D CAD dosyaları aşağıdaki tüm sayfalarda mevcuttur.

CS4F

No. Unit No. Bearing No. Shaft Dia. L J Bolt Size Cr Cor
1 CS4F08-107 22208-107CS 1 7/16 in 4 25/32 in 3 17/32 in 1/2 in 20408 lbf 21623 lbf
2 CS4F08-108 22208-108CS 1 1/2 in 4 25/32 in 3 17/32 in 1/2 in 20408 lbf 21623 lbf
3 CS4F08-040 22208-040CS 40 mm 121 mm 89.7 mm M12 90.7 kN 96.1 kN
4 CS4F09-111 22209-111CS 1 11/16 in 5 1/8 in 2 57/64 in 1/2 in 21150 lbf 23625 lbf
5 CS4F09-112 22209-112CS 1 3/4 in 5 1/8 in 2 57/64 in 1/2 in 21150 lbf 23625 lbf
6 CS4F09-045 22209-045CS 45 mm 130 mm 98.8 mm M12 94 kN 105 kN
7 CS4F10-115 22210-115CS 1 15/16 in 5 5/16 in 4 1/16 in 1/2 in 22095 lbf 25313 lbf
8 CS4F10-050 22210-050CS 50 mm 135 mm 103.2 mm M12 98.2 kN 112.5 kN
9 CS4F10-200 22210-200CS 2 in 5 5/16 in 4 1/16 in 1/2 in 22095 lbf 25313 lbf
10 CS4F11-055 22211-055CS 55 mm 149 mm 114.7 mm M16 122 kN 145 kN
11 CS4F11-203 22211-203CS 2 3/16 in 5 27/32 in 4 33/64 in 5/8 in 27450 lbf 32625 lbf
12 CS4F11-204 22211-204CS 2 1/4 in 5 27/32 in 4 33/64 in 5/8 in 27450 lbf 32625 lbf
13 CS4F13-060 22213-060CS 60 mm 156 mm 121.4 mm M16 178 kN 212 kN
14 CS4F13-207 22213-207CS 2 7/16 in 6 1/8 in 4 25/32 in 5/8 in 40050 lbf 47700 lbf
15 CS4F13-208 22213-208CS 2 1/2 in 6 1/8 in 4 25/32 in 5/8 in 40050 lbf 47700 lbf
16 CS4F13-065 22213-065CS 65 mm 156 mm 121.4 mm M16 178 kN 212 kN
17 CS4F15-211 22215-211CS 2 11/16 in 7 7/32 in 5 9/16 in 3/4 in 42075 lbf 51300 lbf
18 CS4F15-212 22215-212CS 2 3/4 in 7 7/32 in 5 9/16 in 3/4 in 42075 lbf 51300 lbf
19 CS4F15-070 22215-070CS 70 mm 183 mm 141.3 mm M20 187 kN 228 kN
20 CS4F15-215 22215-215CS 2 15/16 in 7 7/32 in 5 9/16 in 3/4 in 42075 lbf 51300 lbf
21 CS4F15-075 22215-075CS 75 mm 183 mm 141.3 mm M20 187 kN 228 kN
22 CS4F15-300 22215-300CS 3 in 7 7/32 in 5 9/16 in 3/4 in 42075 lbf 51300 lbf
23 CS4F18-080 22218-080CS 80 mm 210 mm 170.7 mm M20 302 kN 373 kN
24 CS4F18-304 22218-304CS 3 1/4 in 8 9/32 in 6 23/32 in 3/4 in 67950 lbf 83925 lbf
25 CS4F18-085 22218-085CS 85 mm 210 mm 170.7 mm M20 302 kN 373 kN
26 CS4F18-307 22218-307CS 3 7/16 in 8 9/32 in 6 23/32 in 3/4 in 67950 lbf 83925 lbf
27 CS4F18-308 22218-308CS 3 1/2 in 8 9/32 in 6 23/32 in 3/4 in 67950 lbf 83925 lbf
28 CS4F18-090 22218-090CS 90 mm 210 mm 170.7 mm M20 302 kN 373 kN
29 CS4F20-095 22220-095CS 95 mm 235 mm 193.3 mm M22 371 kN 471 kN
30 CS4F20-100 22220-100CS 100 mm 235 mm 193.3 mm M22 371 kN 471 kN
31 CS4F20-315 22220-315CS 3 15/16 in 9 1/4 in 7 39/64 in 7/8 in 83475 lbf 105975 lbf
32 CS4F20-400 22220-400CS 4 in 9 1/4 in 7 39/64 in 7/8 in 83475 lbf 105975 lbf

CS 4 Cıvata Flanşı Üniteleri Kurulumu

CS 4 Cıvata Flanşı Genişletme Üniteleri Kurulumu

2D ve 3D CAD dosyaları aşağıdaki tüm sayfalarda mevcuttur.

CS4FC

No. Unit No. Bearing No. Shaft Dia. L H3 J Bolt Size Cr Cor
1 CS4FC08-107 22208-107CS 1 7/16 in 5 1/4 in 3 5/8 in 4 3/8 in 3/8 in 20408 lbf 21623 lbf
2 CS4FC08-108 22208-108CS 1 1/2 in 5 1/4 in 3 5/8 in 4 3/8 in 3/8 in 20408 lbf 21623 lbf
3 CS4FC08-040 22208-040CS 40 mm 133 mm 92.1 mm 111.1 mm M10 90.7 kN 96.1 kN
4 CS4FC09-111 22209-111CS 1 11/16 in 6 5/32 in 4 1/4 in 5 1/8 in 1/2 in 21150 lbf 23625 lbf
5 CS4FC09-112 22209-112CS 1 3/4 in 6 5/32 in 4 1/4 in 5 1/8 in 1/2 in 21150 lbf 23625 lbf
6 CS4FC09-045 22209-045CS 45 mm 156 mm 107.8 mm 130.2 mm M12 94 kN 105 kN
7 CS4FC10-115 22210-115CS 1 15/16 in 6 3/8 in 4 1/2 in 5 3/8 in 1/2 in 22095 lbf 25313 lbf
8 CS4FC10-050 22210-050CS 50 mm 162 mm 114.3 mm 136.5 mm M12 98.2 kN 112.5 kN
9 CS4FC10-200 22210-200CS 2 in 6 3/8 in 4 1/2 in 5 3/8 in 1/2 in 22095 lbf 25313 lbf
10 CS4FC11-055 22211-055CS 55 mm 181 mm 127 mm 152.4 mm M12 122 kN 145 kN
11 CS4FC11-203 22211-203CS 2 3/16 in 7 1/8 in 5 in 6 in 1/2 in 27450 lbf 32625 lbf
12 CS4FC11-204 22211-204CS 2 1/4 in 7 1/8 in 5 in 6 in 1/2 in 27450 lbf 32625 lbf
13 CS4FC13-060 22213-060CS 60 mm 194 mm 139.7 mm 165.1 mm M12 178 kN 212 kN
14 CS4FC13-207 22213-207CS 2 7/16 in 7 5/8 in 5 1/2 in 6 1/2 in 1/2 in 40050 lbf 47700 lbf
15 CS4FC13-208 22213-208CS 2 1/2 in 7 5/8 in 5 1/2 in 6 1/2 in 1/2 in 40050 lbf 47700 lbf
16 CS4FC13-065 22213-065CS 65 mm 194 mm 139.7 mm 165.1 mm M12 178 kN 212 kN
17 CS4FC15-211 22215-211CS 2.6875 in 8 3/4 in 6 3/8 in 7 1/2 in 5/8 in 42075 lbf 51300 lbf
18 CS4FC15-212 22215-212CS 2 3/4 in 8 3/4 in 6 3/8 in 7 1/2 in 5/8 in 42075 lbf 51300 lbf
19 CS4FC15-070 22215-070CS 70 mm 222 mm 161.9 mm 190.5 mm M16 187 kN 228 kN
20 CS4FC15-215 22215-215CS 2 15/16 in 8 3/4 in 6 3/8 in 7 1/2 in 5/8 in 42075 lbf 51300 lbf
21 CS4FC15-075 22215-075CS 75 mm 222 mm 161.9 mm 190.5 mm M16 187 kN 228 kN
22 CS4FC15-300 22215-300CS 3 in 8 3/4 in 6 3/8 in 7 1/2 in 5/8 in 42075 lbf 51300 lbf
23 CS4FC18-080 22218-080CS 80 mm 260 mm 187.3 mm 219.1 mm M20 302 kN 373 kN
24 CS4FC18-304 22218-304CS 3 1/4 in 10 1/4 in 7 3/8 in 8 5/8 in 3/4 in 67950 lbf 83925 lbf
25 CS4FC18-085 22218-085CS 85 mm 260 mm 187.3 mm 219.1 mm M20 302 kN 373 kN
26 CS4FC18-307 22218-307CS 3 7/16 in 10 1/4 in 7 3/8 in 8 5/8 in 3/4 in 67950 lbf 83925 lbf
27 CS4FC18-308 22218-308CS 3 1/2 in 10 1/4 in 7 3/8 in 8 5/8 in 3/4 in 67950 lbf 83925 lbf
28 CS4FC18-090 22218-090CS 90 mm 260 mm 187.3 mm 219.1 mm M20 302 kN 373 kN
29 CS4FC20-095 22220-095CS 95 mm 276 mm 206.4 mm 238.1 mm M20 371 kN 471 kN
30 CS4FC20-100 22220-100CS 100 mm 276 mm 206.4 mm 238.1 mm M20 371 kN 471 kN
31 CS4FC20-315 22220-315CS 3 15/16 in 10 7/8 in 8 1/8 in 9 3/8 in 3/4 in 83475 lbf 105975 lbf
32 CS4FC20-400 22220-400CS 4 in 10 7/8 in 8 1/8 in 9 3/8 in 3/4 in 83475 lbf 105975 lbf

CS Flanşı Kartuş Üniteleri Kurulumu

CS Flanşı Genişletme Kartuş Üniteleri Kurulumu
